Precision Cutting Marble Diamond Wire Saw Rope with Marble-Optimized Diamond Segments and Flexible Rope Core

1台のパソコン
MOQ
To Be Negotiable
価格
Precision Cutting Marble Diamond Wire Saw Rope with Marble-Optimized Diamond Segments and Flexible Rope Core
特徴 ギャラリー 製品の説明 見積依頼
特徴
仕様
商標: XIANDAの機械類
タイプ: ダイヤモンド ワイヤーは見た
ビードのタイプ: ダイヤモンド の 数珠
材料: ダイヤモンド/スチール/ゴム/プラスチック
起源: 柔術、福建、中国
線径: 8.8mm/11mm/11.5mm/カスタマイズされた
使用法: 大理石の切断
キーワード: 大理石プロファイリングツール、石切断ロープ、大理石用ダイヤモンドロープ、精密大理石カッター、大理石加工ツール、曲石切断ロープ
ハイライト:

Precision Cutting Marble Diamond Wire Saw

,

Marble-Optimized Diamond Segments Wire Saw Rope

,

Flexible Rope Core Diamond Wire Saw

基本情報
起源の場所: 柔術、福建、中国
ブランド名: Xianda Machinery
証明: API, CCC, SONCAP, GOST, ISO, CE, SGS;IAF
モデル番号: 大理石用ダイヤモンドワイヤーソーロープ
お支払配送条件
パッケージの詳細: プラスチックフィルム + カートン、海/空/陸/鉄道輸送に適しています。
受渡し時間: 7日間
支払条件: L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム
供給の能力: 1000セット/年
製品の説明
Marble Profiling Tools Diamond Wire Saw Rope – Precision Cutting for Marble & Stone
Product Overview
The Marble Profiling Tools Diamond Wire Saw Rope is engineered to deliver unmatched precision and efficiency in marble processing, from intricate profiling to large-scale cutting. Crafted with high-grade diamond segments and a durable core, this tool ensures clean, smooth cuts on marble, travertine, onyx, and other soft-to-medium stone materials—making it indispensable for stone fabricators, sculptors, and construction professionals.
Key Features
  • Marble-Optimized Diamond Segments: Embedded with fine-grade industrial diamonds, designed to glide through marble without chipping or cracking, preserving the stone's natural beauty.
  • Flexible, Durable Rope Core: Constructed with high-tensile steel cables and a wear-resistant polymer coating, ensuring flexibility for curved cuts and longevity under continuous use.
  • Precision Profiling Capability: Perfect for detailed shaping, edge profiling, and complex contours—ideal for custom countertops, architectural elements, and artistic sculptures.
  • Low Material Waste: Produces ultra-narrow kerfs (cutting widths), minimizing marble loss and maximizing material utilization for cost-effective projects.
Feature Benefit
Vacuum-brazed diamond beads Higher diamond exposure = 30% faster cutting
Steel-core reinforcement Anti-fatigue, anti-breakage, suitable for high-speed saws
Multi-strand construction Flexible, kink-resistant, fits tight radius cuts
Wet & dry use Works with water cooling or dry cutting (wet recommended)
Customisable specs Diameter, length, bead spacing on request
Specification Range
Parameter Standard Options Custom Range
Diameter Ø8.8 mm / Ø11 mm / Ø11.5 mm Ø7-Ø14 mm
Bead spacing 25 mm / 40 mm 20-50 mm
Length 10 m / 20 m / 50 m 10-50 m
Wire speed 20-40 m/s (machine dependent) Up to 50 m/s
Bond type Medium, Hard Custom for granite hardness
Core type Rubber / Plastic / Spring Multi-layer steel
Technical Benefits
  • Smooth, Chip-Free Cuts: The specialized diamond grit and rope tension control prevent surface damage, reducing post-cut finishing time.
  • High Efficiency: Cuts through marble up to 30% faster than traditional saws, accelerating project timelines for both small workshops and large-scale operations.
  • Versatile Compatibility: Works seamlessly with most wire saw machines, including stationary and portable models, for on-site or in-factory use.
Pricing & Service Cycle
Item Detail
MOQ 1 reel (any length)
Shipping Sea freight to nearest port included
Lead time 7 days stock / 15 days custom
Payment T/T 30% deposit, 70% before shipment; L/C at sight accepted
Why Choose Our Marble Diamond Wire Saw Rope?
  • Marble-Specific Design: Engineered to handle marble's unique texture, ensuring precision without compromising aesthetics.
  • Cost Savings: Reduced waste, fast cutting speeds, and long lifespan lower operational costs.
  • Trusted Quality: Used by leading stone fabricators worldwide for consistent, reliable results.
  • End-to-End Support: From selection to after-sales, our experts guide you to maximize productivity.
Ready to elevate your marble processing? Contact us today to place an order, request a sample, or get a personalized quote.
